Model:AS-ZJYP-40T
Product Origin:China
Product Description:This machine adopts electric hydraulic drive and an integrated upper plate rocker arm structure.
Equipment Introduction:
Automatic isostatic press machine adopts electric hydraulic drive and an integrated upper plate rocker arm structure. Due to its beautiful appearance, simple operation process, intelligent program control system, stable and reliable pressure data, and multiple safety protection devices, it is deeply loved by users and suitable for high-end laboratory use.
Main technical parameters:
|
Model |
AS-ZJYP-40T |
|
Pressure range |
0.4-40T/0.1t |
|
Piston diameter |
130mm |
|
Maximum cylinder stroke |
<40mm |
|
Pressure way/method |
Automatic pressurization/slow pressurization |
|
Pressure sampling process |
Automatic pressurization - automatic pressure maintenance - precise pressure replenishment - timed pressure relief |
|
Number of pressurized sections |
Five sections can be set arbitrarily |
|
Hold pressure time |
Unlimited N seconds, each segment can be set with different holding times |
|
Control panel |
XNNETS 7-inch touch LCD screen (remote control optional) |
|
Touch screen function module |
Pressure system - Data management system - Chinese English interface exchange, etc. (USB upgradable) |
|
Conversion of mold pressure |
Real time automatic calculation of sample bearing pressure (MPa) |
|
Oil cylinder limit protection |
When the oil cylinder rises and touches the limit switch, it automatically releases pressure |
|
System safety configuration |
Automatically release pressure when the system pressure exceeds the safe value |
|
Safety protection device |
Steel plate protection+bulletproof glass door+leakage protection+emergency stop switch |
|
Power source |
220V (50Hz/60Hz) |
|
Equipment power |
400W |
|
Isostatic pressure chamber/cavity |
Dia. 40mm x 150mm |
|
The cavity is subjected to pressure |
≤300MPa/39t |
|
Dimension |
280×460×660mm |
|
Weight |
180kg |
|
Configuration instruction |
One isostatic press machine! Customized 500MPa static press or rubber mold according to requirements |
